Security concept / geometry / physical tests

Thor’s Hammer.

A .38-caliber paintball or pepper-ball security concept developed through loose thought, measured geometry, printed angle tests, and larger CAD assemblies. This page shows the development trail, not a claim that every sketch was a finished weapon.

Early marker-board sketch labeled Thor's Hammer — 01 / Name and mechanism started as a rough marker-board thought.

Printed circular jig with paintballs used to explore firing angles — 02 / A printed jig made the firing angles physical enough to inspect and change.

CAD assembly for the Thor's Hammer security concept — 03 / The concept moved into CAD so positions, clearances, and the larger assembly could be evaluated.
